Print Technology: Thermal Transfer, Direct Thermal
Resolution: 11.8 dots/mm
Max Print Width: 105.7 mm (4.16 inches)
Print Length: 300 dpi: 2.2 m (7.22 inches)
Print Speed: 50 - 200 mm/s (2-8 ips)
Connectivity Interface: Standard: • USB 2.0 host interface • USB 2.0 device interface • Ethernet interface, transmission rate: 10/100 Mbps • RS-232, transmission rate up to 115.2 KB/s Supports the following serial protocols: • Fingerprint/Direct Protocol: XON/XOFF, ENQ/ACK, RTS/CTS • IPL: XON/XOFF, Honeywell Std. Protocol Optional: • WIFI: IEEE 802.11 a/b/g/n/ac, Static WEP (64 bit and 128 bit), Dynamic WEP (TLS, TTLS, PEAP, LEAP, EAP-FAST), WPA (THIP/CCKM Personal and Enterprise), WPA2 (AES-CCMP/CCKM Personal and Enterprise) • Parallel port: IEEE 1284 • Industrial interface: 8-bit INPUT/output, 4 analog signal relays and 1 RS-232/422/485 port • Dual serial ports: RS-232, RS-422 and RS-485, and 20 mA current loop, GPIO card
Memory: SDRAM 128 MB, Flash 128 MB
CPU: Arm Cortex®-A7, 800MHz 128 MB flash memory 128 MB DDR3 SDRAM Multi-GB USB storage device (FAT16/FAT32) Integrated real-time clock
Ribbon Specifications: Ribbon Type: Inside or outside wound ribbon Max Ribbon Roll Diameter: 80 mm (3.15 inches), approx. 450 m (1,476 feet) Ribbon Core Diameter: 25.4 mm (1 inch) Max and Min Ribbon Width: 110/51 mm (4.33 / 2.0 inch) Ribbon Material: Wax, Wax Resin and Resin
Media Specifications: Max, Min Media Width: 114/20 mm (4.5/0.79 in) Min Media Length: Paper tearing mode: 5.0 mm (0.197 inches) Self-peeling mode: 12.7 mm (0.5 inches) Cutter Mode: 38.0mm (1.5 inches) Media Thickness: 3 mil to 10 mil (0.076mm to 0.255mm) Media Type: Roll or fanfold labels Max Media Roll Diameter: 203.2 mm (8.0 inch) Media Core: 76 mm (3.0 inch) /25.4 mm (1.0 inch)
Printer Dimensions (L x H x W): PD45S0F/PD45S0C 438 mm x 270 mm x 249 mm (17.24 in x 10.63 in x 9.80 in)
Printer Weight: 10.82 kg (23.85 lbs)
Optional Features and Accessories: • Wireless network interface card (optional) • Parallel interface card • Labeling machine interface card • Industrial GPIO interface card • Peeling and rewind assembly • Cutter
Environment: Operating Temperature: +5°C to +40°C (+41°F to +104°F) Storage Temperature: -20°C to +70°C (-4°F to +158°F) Humidity: 20 - 85% non-condensing
BARCODES/FONTS/GRAPHICS: Barcodes: Supports all 1D and 2D barcodes. Supports standards: UPC/EAN Shipping Container, UCC/EAN 128, Serial Shipping Container, MH10.8 Shipping Label, AIAG (shipping parts label, OGMARS, POSTNET, HIBCC, ISBT 128, GM1724, UPS Shipping Label and Global Transport Label. Fonts: Monotype font engine; Non-Latin fonts can be supported via WTLE and customers can also download fonts themselves (Truetype). Graphics: Supports PCX, PNG, GIF, and BMP file formats. Other formats may be supported by Label Generation Tools.
Printer Command Languages: Fingerprint (FP), Direct Protocol (DP), IPL, ZSim2 (ZPL-II), DPL; XML can be enabled for SAP AII and Oracle WMS.
User Interface Languages: Color CNC LCD interface and WEB interface: English, Italian, French, Spanish, Portuguese, German, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, and Thai.
