MECHANICAL
Dimensions (L x W x H):105 mm x 102 mm x 150 mm (4.1 in x 4.0 in x 5.9 in)
Weight: 400 g (14.1 oz)
ELECTRICAL
Input Voltage: 5 VDC ±0.25 V
Operating Power: 900 mW (180 mA @ 5 V)
Standby Power: 850 mW (170 mA @ 5 V)
Host System Interfaces: USB, RS-232, Keyboard Wedge, IBM 468xx (RS485)
ENVIRONMENTAL
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 60°C (-40°F to 140°F)
Humidity: 5% to 95% relative humidity, non-condensing
Drop: Designed to withstand 1.2 m (4 ft) drops
Environmental Sealing: Sealed to resist airborne particulate contaminants
Light Levels: 4842 Lux
SCAN PERFORMANCE
Scan Pattern: Omnidirectional: 5 fields of 4 parallel lines; button-activated single line (7180)
Scan Speed: Omnidirectional: 1120 scan lines per second; single line: 56 scan lines per second (7180)
Print Contrast: 35% minimum reflectance difference
Pitch, Skew: 60°, 60°
Decode Capability: Reads standard 1D and GS1 DataBar symbologies
