Measurement ranges:
+ PM1/PM2.5/PM10:
0–50 μg/m³ / 0–500 μg/m³ (selectable via jumper)
IAQ index: 1-5 (WHO rating)
+ Temperature: 0...50 °C
+ Relative humidity: 0–100 %rH
Accuracy:
+ PM:
0…100 µg/m3:
PM2.5: ±15 µg/m³ (at 25 ⁰C ±5 ⁰C)
PM1/PM10*: ±25 µg/m³ (at 25 ⁰C ±5 ⁰C)
100…1000 µg/m3:
PM2.5: ±15 % (at 25 ⁰C ±5 ⁰C)
PM1/PM10*: ±25 % (at 25 ⁰C ±5 ⁰C)
*PM1 and PM10 values are calculated from PM2.5 measurement reading with the default particle distribution
+ Temperature: ±0.5 ⁰C (typical at 20 ⁰C)
+ Relative humidity: ±2.4 %rH (typical at 20 ºC, 30 % rH)
Measuring elements:
+ CO2: Non-dispersive infrared (NDIR)
+ VOC: Complementary Metal Oxide Semiconductor (CMOS)
+ PM: Laser-based light scattering particle sensing
+ Temperature: Integrated to CMOS
+ Relative humidity: Thermoset polymer capacitive sensing element
Measuring units:
+ CO2: ppm
+ Relative humidity: % rH
+ Temperature: °C
+ VOC: CO2eq: ppm; TVOC: ppm, μg/m3
+ PM1/2.5/10: μg/m3
Calibration (CO2): Automatic self-calibration, ABC LogicTM
Supply voltage: 24 VDC/VAC ±10 %
Output signal 1–4:0...10 V (optional 2...10 V / 0...5 V, display or configuration tool required); Optional: 4...20 mA; Linear to selected measurement (CO2, VOC, PM, rH or Temp)
Operating temperature: 0...50 °C
Protection standard: IP20
Noted:
PM = Particulate Matter sensor
rH = Humidity sensor
T = Temperature sensor,
A = mA output
