Pitch: 0.8 mm
Housing Color: Black
Contact Gender: Socket (Female)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 40 VAC, 30 VDC
Wire Gauge Max: 24 AWG
Wire Gauge Min: 32 AWG
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Polyamide (PA)
Wire Gauge Range: 32 AWG to 24 AWG
Termination Style: Crimp
Number of Positions: 3 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 30 C
