Pitch: 0.8 mm (0.031 in)
Application: PCIe Gen 4
Stack Height: 10 mm, 12 mm
Current Rating: 500 mA
Mounting Angle: Straight
Mounting Style: PCB Mount
Number of Rows: 2 Row
Voltage Rating: 100 VAC
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Maximum Data Rate: 16 Gbps
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 50 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
