Color: Black
Pitch: 1.27 mm
Gender: Male
Unit Weight: 13 g
Cable Diameter: 0.5 mm
Current Rating: 500 mA
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 125 VAC
Contact Plating: Gold
Number of Ports: 1 Port
Contact Material: Copper Alloy
Housing Material: Zinc
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Insulation Material: Polybutylene Terephthalate (PBT)
Number of Positions: 28 Position
Insulation Resistance: 250 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
