Interface: Bluetooth (Standard), RS-232 (Optional)
Meas.range:
N・m: 0.15-10.00
N・cm: 15-1000
lbf・in: 1.5-90.0
kgf・cm: 1.5-100.0
Measuring unit: N・m⇔kgf・
Min. display unit: 10digit
Meas. mode: PEAK, TR1 (torque waveform), TR2 (continuous torque waveform)
Meas. direction: Right-hand screw, left-hand screw
Meas. accuracy: Within ±0.5% (F.S.)
Charging and scalability:
Supports the following with a micro USB Type-B port: Charging, Data transfer (USB 2.0: up to 480Mb/s)
Battery&Power:
Input: AC100-240V 50/60Hz 0.4A
Output: DC5V 2A 10W
All models are equipped with 1000 mA Ni-MH battery 3.6 V (operating voltage 3.3 V), maximum 300 mA when the power is ON
Torque meas & data transmission: Up to 2.5 hours, Charging via power adapter or PC via USB port
Charging time: 5 hours
Charge cycles: 500
Power consumption: Max. 1.5 W or less
Size (W x D x H): 230 x 110 x 50 mm (excluding the largest protrusion)
Weight: 1.94kg
