Measurement system: Two-electrode method/three-electrode method (switchable)
Measurement range: 20 Ω (0 Ω〜20.00 Ω)/ 200 Ω (0 Ω〜200.0 Ω)/ 2000 Ω (0 Ω〜2000 Ω)
Accuracy: ±1.5% rdg ±8 dgt/ ±1.5% rdg ±4 dgt/ ±1.5% rdg ±4 dgt
Earth voltage: 0〜30.0 V rms
Accuracy: ±2.3% rdg ±8 dgt (50 Hz/60 Hz), ±1.3% rdg ±4 dgt (DC)
Allowable earth potential: 25.0 V rms (DC or sine wave)
Dustproof and waterproof: IP65/IP67 (EN60529)
Power supply: LR6 Alkaline battery ×4, Possible number of measurements: 500 times (measurement conditions: three-electrode method, measuring 10 Ω at 10-second intervals without Z3210 installed)
Functions: Live wire warning, zero-adjustment, continuous measurement mode, wireless communication (only when Z3210 is connected), and comparator
Dimensions and mass: 185 mm (7.28 in)W × 111 mm (4.37 in)H × 44 mm (1.73 in)D, 570 g (20.1 oz.) (including batteries and protector, excluding terminal covers and other accessories)
Accessories: Auxiliary Earthing Rod L9840 (2 piece set) ×1,
Measurement Cable L9841 (black 4 m) ×1,
Measurement Cable L9842-11 (yellow 10 m, equipped with winder) ×1,
Measurement Cable L9842-22 (red 20 m, equipped with winder) ×1,
Carrying Case C0106 ×1, Protector ×1,
LR6 Alkaline battery ×4,
Instruction manual ×1
