Measurement functions: Number of channels: 2, for voltage measurement
Input connectors: Isolated BNC connector (input impedance 1 MΩ, input capacitance 30 pF), Max. rated voltage to earth: 300 V AC, DC (with input isolated from the unit, the maximum voltage that can be applied between input channel and chassis and between input channels without damage)
Measurement range: 5 mV to 20 V/div, 12 ranges, full scale: 20 div, (AC voltage for possible measurement/display using the memory function: 280 V rms)
Low-pass filter: 5/50/500 Hz, 5 k/50 k/500 kHz
Measurement resolution: 1/100 of measurement range (using 12-bit A/D conversion and when installed in the 8847)
Highest sampling rate: 20 MS/s (simultaneous sampling across 2 channels)
Measurement accuracy: ±0.5 % of full scale (with filter 5 Hz, zero position accuracy included)
Frequency characteristics: DC to 5 MHz -3 dB, with AC coupling: 7 Hz to 5 MHz -3dB
Input coupling: AC/DC/GND
Max. allowable input: 400 V DC (the maximum voltage that can be applied across input pins without damage)
Dimensions and mass: 106 mm (4.17 in) W × 19.8 mm (0.78 in) H × 196.5 mm (7.74 in) D, 250 g (8.8 oz)
Included accessories: None
