Viewing Head: Monocular Inclined at 45°,360°Rotatble
Eyepiece: WF10X/18mm
Objective: Achromatic 4X, 10X, 40X(S), 100X(S) Oil
Nosepiece: Backward Quadruple Nosepiece
Stage: Double layer mechanical stage; StagSizexe: 140mm × 132mm; Moving Range: 70mm × 30mm
Condenser: N.A.1.25 Abbe condenser with iris diaphragm and filter
Focusing: Coaxial coarse & fine focusing adjustment Fine focusing scale value 0.002mm
Light Source: Halogen bulb 6V20W or 6V15W, AC 220V/110V; Adjustable light intensity
Optional Accessory:
Eyepiece: WF16X, WF20X, P16X
Objective：20X, 60(S)
Semi-plan Objective: 4X, 10X, 20X, 40X(S), 60X(S), 100X(S) Oil
Plan Objective: 4X, 10X, 20X, 40X(S), 60X(S), 100X(S) Oil
Compensation Free Binocular & Trinocular Head (48mm-75mm)
LED illumination
