Display Mode: CIEL*a*b; CIE XYZ; CIE RGB; CIEL*u*V; CIE*C*H; Whiteness &Yellowness; Colorfastness
Color Difference Formula: △E*ab；△L*a*b; △E*C*h; △ECIE94; △E Hunter
Illuminating/Viewing geometry: 8/d(8°illumination angle/diffuse viewing)
Light source: LED blue light excitation
Detector: Silicon photoelectric diode
Measuring Aperture: Φ8mm; φ4mm; φ8mm extended aperture(optical)
Measuring Conditions: Observer: CIE 10°standard observer; Illuminant: CIE standard illuminant D65
Measuring Range: L: 0 to 100
Repeatability: Standard deviation within △E*ab 0.08(Measurement conditions: Average of 30 measurements of standard white plate)
Storage: 100 pcs standard samples;20000 pcs test samples
Minimum Interval Between Measurement: Approx. 1 sec
Battery Life: More than 3000 times
Lamp Life: more than 1.6 million times in 5 years
Display: TFT true color 2.8inch at (16:9)
Interface: Model B: USB; RS-232: Baud rate 19200bps
Operating Temperature Range: -10 – 40℃（32 – 104℉）
Storage Temperature: -20 – 50℃（-4 – 122℉）
Humidity Range: Relative humidity 0 – 85% with no condensation
Weight: 500g
Dimensions: 205mmx 70mm x100mm
Size of the packing: 435mm 205mm 345mm
Standard Accessories: AC Adapter; Li-ion Battery; Operation Manual; Software CD; USB Cable; White Calibration Cover; Φ8mm Measuring Aperture Mini-printer; Printer Cable
Operation Accessories: Extended Aperture(Φ8mm); Mini-printer; Printer Cable, Universal Test Components, Powder Test Box
