Technical data:
Configuration: Semi-automatic control
The main material: Stainless steel
Volume/GWL: 75L/101Kg
Voltage/Power: 220V/3.5Kw
Product size(L X W X H mm): 570 x 670 x 1340
Sterilization chamber volume (D X H mm) 370 x 700
Packing size (L X W X H mm): 760x650x1430
Basket size(D X H mm): 335 x 190 x 3↑
Time setting range: 0-99 h
Rated working pressure: 0.142Mpa
Sterilization temperature: 50˜126°C
Features
1. Hand wheel lid structure
2.Automatic control of the sterilization cycle program
3. Interactive safety interlock device
4.Water supply cut protecting equipment
5.Digital windows display working status
6.Time setting range (0-99Hours)
7.The work pressure is 0.165Mpa
8.Sterilization temperature setting range (50°C-126°C)
9 Double scale numerical indication pressure gauge
10 Self inflating type seal
11 Sterilization end automatic alarm
Main parts
1. Pressure temperature switch/ High pressure: 1
2. Power switch/250V 15A: 1
3. Solid-state relay/440V 40A: 1
4. Heater/3.5Kw: 1
5. Spring loaded safety valve/0.217-0.24Mpa: 1
6. Pressure gauge/1.6class: 1
7. Relief valve/0.25Mpa: 1
8. Seal ring: 1
9. Computer board: 1
10. Fuse/380V 25A: 1
