Eyepiece: Wide field WF10X(Φ18mm)
Objective: Achromatic 4X/0.10; Achromatic 10X/0.25; Achromatic 40X/0.65(Spring); Achromatic 100X/1.25(Spring, oil)
Eyepiece tube: Monocular, 360˚ rotatable (Inclination of 45˚)
Focus system: Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm
Nosepiece: Quadruple(Frontward ball bearing outer locating)
Stage: Fixed, with slide moving holder Size: 120mmX120mm, move range: 70mmX30mm
Abbe condenser: N.A.1.25 Spiral adjustment
Filter: Blue filter; Frosted filter
Collector: For incandescent lamp
Light source: 220V/110V 20W, Incandescent lamp
