Rated input voltage (DC): 11 kV
Rated input voltage (AC eff.): 8 kV
Rated input voltage (Pulse 1.2/50µs): 20 kV
Divider ratio (DC): 1000:1 (± 1%)
HV-resistor: 20 MΩ
HV-capacitor: 75 pF
Rise time: 15 ns
Bandwidth: 23 MHz
Dimensions:
Socket (∅/L x B x H): 112 x 60 x 32 mm
Undercarriage (L x W): -
Wheels / lockable: -
Height: 240 mm
Weight: 1.5 kg
Cable length: 2 m
Environment Conditions
Temperature range: 5 °C - 40 °C
Temperature error: < 0.2 % (from -5 °C to 40 °C)
Relative humidity: Maximum 80% for temperatures up to 31 °C, decreasing linearly to 50% at 40 °C
Operating Altitude: Up to 1000 m above sea level
