Coupling-/Decoupling Network for I/O lines L1, L2, L3, L4, PE
Nominal voltage AC/DC: 240 V
Nominal current AC/DC: 10 A
max. test voltage Surge, 1.2/50 µs: 2.5 kV
max. test voltage Burst, 5/50 ns: 2.5 kV
Coupling impedance for the surge generator:
0.1 µF / 0.5 µF + 40 Ω
Varistor + 40Ω
Coupling impedance for the burst generator: 33 nF
Coupling mode, selectable, for the surge generator:
line to line via 0.1/0.5 µF or
line to ground via 0.1/0.5 µF
Coupling mode, selectable, for the burst generator: line to ground via 33 nF
Burst Input: Fischer
Surge Input: 4 mm Bush
Mains power: 90V - 264V, 50/60 Hz
Dimensions: desk top case W * H * D 450*180*500 mm3
Weight: 25 kg
