Nominal voltage AC/DC: 3 * 400 V, 50/60 Hz / 400V DC
Nominal current AC/DC: 63A
Series inductors to the mains power supply: <1.5 mH + >100 µH
max. test voltage Surge, 1.2/50 µs: 10 kV
max. test voltage Burst, 5/50 ns: 5.0 kV
Coupling impedance for the surge generator: 18 µF; 9 µF + 10 Ω
Coupling impedance for the burst generator: 33 nF
Coupling mode, selectable, for the surge generator:
line to line via 18 µF or
line to ground 9 µF + 10 Ω
Coupling mode, selectable, for the burst generator:
line to ground via 33 nF
Impuls Synchronisation: Mains, Extern
Burst Input: Fischer
Surge Input: 4 mm Bush
Mains power: 90V - 264V, 50/60 Hz
Dimentions (W * H * D / mm3): 450*310*500
Weight: 90kg
