Infrared Image
IR Resolution: 640 × 480 (307,200 pixels)
NETD: < 30 mK (@ 25 °C, F#=1.0)
Image Frequency: 30 Hz
Detector Pitch: 17 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 12.6 mm
F-number: F1.0
Field of View (FOV): 24.8° × 18.7°
Spatial Resolution (IFOV): 1.35 mrad
Focus Mode: Laser Assisted AF/Continuous AF/AF/Manual Focus/Touch AF
Focus Speed: Approx. 1 second
Min. Focus Distance: 0.15 m (0.49 ft)
SuperIR: 1280 x 960 (1,228,800 pixels)
Image Display
Visual Camera: 3264 × 2448 (8 MP)
Display: 1280 × 720 Resolution, 5” LCD Touch Screen
Screen Brightness: Manual/Auto
Viewfinder: 1024 × 768 pixels OLED
Digital Zoom: 1.x to 12.x continuous
Image Modes: Thermal / Visual / Fusion / PIP / Blending
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode Palette: Above / Below / Interval
Color Alarm: Above / Below / Interval / Insulation
Measurement and Analysis
Temperature Range Setting:
Range 1: -40°C to 150°C
Range 2: 0°C to 650°C
Auto Switch
Accuracy: Max. (± 2°C/3.6°F, ± 2%)
Measurement Tools: Center Spot, Hot Spot, Cold Spot User-definable: 10 spots, 1 line, 10 rectangles
Level and Span Mode: Auto / Manual / 1-Tap Touch-screen
Inspection Route: Yes
Data Storage and Communication
Storage Media: Removable 64 GB SD Card
Image Storage Capacity: Approx. 60,000 Images
Annotations: Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity: Approx. 64 hours
Video File Format: MP4 video and radiometric video
General
Wi-Fi: 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth: Bluetooth 4.2
USB Interface: USB Type-C
HDMI Interface: HDMI-D
LED Light: Yes
Laser: Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Laser Distance Meter: Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).---fandan
GPS & Compass: Yes
Battery Type: Interchangeable and rechargeable Li-ion battery
Battery Operating Time: Approx. 4 hours
Battery Charging Time: Approx. 2.5 hours fully charged
Power Saving Mode: Yes
Programmable Buttons: 2
Protection Level: IP54, IEC 60529
Drop Test Height: 1 m (3.28 ft), IEC 60068-2-31
Safety: IEC 61010-1
EMC: EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-3
Vibration: 2 g, IEC 60068-2-6
Shock: 25 g, IEC 60068-2-27
Working Temperature Range: -20°C to 50°C ( -4°F to 122 °F)
Storage Temperature Range: -20°C to 60°C ( -4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 1481 g (3.27 lb)
Dimension: 204.7 × 153.6 × 87.8 mm (8.06 × 6.05 × 3.45 in)
Tripod Mounting: UNC ¼”-20
