- Thermal Module
Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512
Frame Rate: 50 Hz
Pixel Interval: 12 μm
Response Waveband: 8 μm to 14 μm
NETD: <35 mK (@25 °C, F# = 1.2)
Lens (Focal Length): 50 mm
Detection Range: 2600 m
Focus Mode: Manual
Field of View: 8.78° × 7.03° (H × V)
Min. Focusing Distance: 5 m
Aperture: F1.2
Magnification: 2.9
Digital Zoom: 1X, 2X, 4X, 8X
- Optical Module
Image Sensor: 1/2” Progressive Scan CMOS
Focal Length: 22 mm
Wavelength: 400 nm to 1000 nm
Max. Resolution: 1920 × 1080
Min. Illumination: 0.001 Lux@F1.0
- Image Display
Frame Frequency: 50 Hz
Display: 0.39 inch, OLED, 1024 × 768
Image Mode: White Hot, Black Hot, Red Hot, Fusion, Visible, Image Fusion
- Power Supply
Battery Type: One 18650 battery
Battery Operating Time: 4.5 hours
Power: Removable Battery
- General
Protection Level: IP67
Dimension: 87.2 mm × 73.3 mm × 183.6 mm
Weight: 548 g
Working Temperature: -30 to 55 °C
- Laser Rangefinder
Safety Class for Laser: Class 1
Wavelength: 905 nm
Max. Measuring Range: 600 m
Measurement Accuracy: ±1 m
