Infrared Image
IR Resolution: 640 × 480 (307,200 pixels)
SuperIR: 1280 × 960 (1228800 pixels)
NETD: < 35 mK (@ 25°C, F# = 1.0)
Image Frequency: 50 Hz
Detector Pitch: 17 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 25 mm
F-number: F1.0
Field of View (FOV): 25° × 19°
Spatial Resolution (IFOV): 0.68 mrad
Min. Focus Distance: 0.3 m (0.98 ft)
Focus Mode: Laser Assisted AF/Continuous AF/AF/Manual Focus/Touch AF
Focus Speed: Approx. 2 second
Image Display
Visual Camera: 3264 × 2448 (8 MP)
Display: 800 × 480 Resolution, 4.3" LCD Touch Screen
Screen Brightness: Manual/Auto
Digital Zoom: 1.0x to 8.0x continuous
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode: Palette Above/Below/Interval
Color Alarm: Above/Below/Interval/Insulation
Image Modes: Infrared/Visual/Fusion/PIP/Blending
Measurement and Analysis
Object Temperature Range: -20°C to 2200°C (-4°F to 3632°F)
Accuracy: Max. (± 2°C/3.6°F, ± 2%)
Measurement Tools: Center Spot, Hot Spot, Cold Spot; User-definable: 10 spots, 1 line, 5 rectangles, and 5 circle
Level and Span Mode: Auto/Manual/1-Tap Touch-screen
Inspection Route: Yes
Data Storage and Communication
Storage Media: Removable 64 GB MicroSD Card
Image Storage Capacity: Approx. 60,000 Images
Annotations: Voice note: max. 60 seconds; Text note: max. 200 characters
Video Storage Capacity: Approx. 54 hours
Video File Format: MP4 video and radiometric video
General
Wi-Fi: 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth: Bluetooth 4.2
USB Interface: USB Type-C
HDMI Interface: Yes
LED Light: Yes
Laser: Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Laser Distance Meter: Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).
Battery Type: Interchangeable and rechargeable Li-ion battery
GPS & Compass: Yes
Battery Operating Time: Approx. 4 hours
Battery Charging Time: Approx. 4 hours fully charged
Power Saving Mode: Yes
Protection Level: IP54, IEC 60529
Drop Test Height: 2 m (6.56 ft), IEC 60068-2-31
Safety: IEC 61010-1
EMC: EN 301 489-1, EN 301 489-17, EN IEC 61000-6-2, EN IEC 61000-6-3
Vibration: 2 g, IEC 60068-2-6
Shock: 25 g, IEC 60068-2-27
Working Temperature Range: -20°C to 50°C (-4°F to 122°F)
Storage Temperature Rang: -20°C to 60°C (-4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 1058 g (2.33 lb)
Dimension: 284.7 mm × 120.6 mm × 124.5 mm (11.21” × 4.75” × 4.9”)
Tripod Mounting: UNC ¼”-20
