Infrared Image
IR Resolution 96 × 96 (9,216 pixels)
SuperIR 240 × 240 (57,600 pixels)
Distance to Spot Ratio (D:S) 112:1
NETD < 50 mK (@ 25°C, F# = 1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 1.35 mm
F-number: F1.0
Field of View (FOV): 50° × 50°
Spatial Resolution (IFOV): 8.89 mrad
Min. Focus Distance: 0.1 m (0.33 ft)
Focus Mode: Focus Free
Image Display
Display: 240 × 320 Resolution, 2.4”LCD Screen
Image Modes: Thermal/Visual/Fusion
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion
Color Alarm: Above alarm
Visual Camera 640 × 480
Measurement and Analysis
Object Temperature Range: -20°C to 550°C (-4°F to 1022°F)
Accuracy: Max. (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)
Measurement Tools: Center Spot, Hot Spot, Cold Spot
Level and Span Mode: Auto/Manual
Data Storage and Communication
Storage Media: Built-in 4 GB flash memory
Image Storage Capacity: Approx. 30,000 Images
General
USB Interface: USB Type-C
Laser: Yes, Class II
Battery Type: Rechargeable Li-ion battery
Battery Charging Time: Approx. 3 hours fully charged (Adapter Output: 5 V 2 A)
Battery Operating Time: Approx. 8 hours
Protection Level: IP54
Drop Test Height: 2 m (6.56 ft)
Working Temperature Range: -10°C to 50°C (14°F to 122°F)
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 290 g (0.64 lb)
Dimension: 196 × 117 × 59 mm (7.7” × 4.6” × 2.3”)
Tripod Mounting: UNC ¼”-20
