Thermal module
Image sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512
Detector Pitch: 17μm
Response waveband: 8μm to 14μm
NETD : < 40mk (@25°C,F#=1.0)
Lens (focal length): 9.3 mm
Focus Mode: Fixed
MRAD: 1.83
Field of View: 72° × 56.1°
Min. Focusing Distance: 1m
F number: 1.0
Optical camera
Image Sensor: 1/1.9’’ Progressive Scan CMOS
Min. Illumination: Color: 0.002 lux @ (F1.5 , AGC On ) B/W : 0.0002 lux @ (F1.5 , AGC On )
Focal Length: 5.7-205.2mm, 36x
Digital Zoom: 16 X
Field of View: 58.7° - 2.0° (Wide-Tele)
Min. Working Distance: 10-1500mm (Wide-Tele)
Aperture Range: F1.5-F4.5
Focus Mode: Auto / Semiautomatic / Manual
WDR: 120dB
Smart function
VCA Support: 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), 10 scenes and 8 VCA rules for each scene.
Temperature Measurement: Support 3 temperature measurement rule types, over 256 presets as scene, 21 rules of each scene (10 points, 10 regions, and 1 line)
Temperature range: -20°C to 550°C (-4°F to 1,022°F)
Temperature accuracy: Max (±2°C, ±2%)
Fire detection: Support 10 fire points
Infrared
IR Distance: Up to 200m
IR Intensity and Angle : Auto Adjust
General
Menu: English
Wiper: Yes
Power: 24V AC, 60W
Work Temperature/Humidity: From -40°C to 60°C (-40°F to 140°F); Humidity: 90% or Less
Protection: Level IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Weight: Approx. 8kg (17.64 lb)
