Thermal Module
Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512
Pixel Interval: 17 μm
Response Waveband: 8 μm to 14 μm
NETD: less than 40mk (@25°C,F#=1.0)
Lens (Focal Length): 25 mm
MRAD: 0.68 mrad
Field of View: 24.55° × 19.75° (H × V)
Min. Focusing Distance: 2 m
Aperture: F 1.0
Smart Function
VCA (Video Content Analysis): 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules.
Temperature Measurement: 3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line).
Temperature Range: -20 °C to 150 °C (-4 °F to 302 °F), 0 °C to 550 °C (32 °F to 1022 °F)
Temperature Accuracy: Max (± 2 °C, ± 2%)
Fire detection: Dynamic fire point detection, up to 10 fire points detectable
General
Menu language: English
Power: 100-240 VAC PoE (802.3at)
Power Consumption: 100-240 VAC, max.15W PoE (802.3at)
Working Temperature/Humidity: -40 °C to 60 °C (-40 °F to 140 °F), 90% or less
Protection Level: IP68 Standard TVS 6000V Lightning protection, surge protection, voltage transient protection
Dimensions: 409.6 mm × 179.2 mm × 183.3 mm (16.14″ × 7.06″ × 7.22″)
Weight: Approx. 19.11 kg (42.13 lb)
Accessarys: Standard: Wall Mounting Bracket DS-1707ZJ-E Optional: Explosion-Proof Tube DS-1677ZJ-XS-1.0, Junction Box DS-1675ZJX-S
