THAY THẾ BẰNG MODEL B20S
Infrared Image
IR Resolution 192 × 144 (27,648 pixels)
NETD < 40 mK (@ 25°C, F# = 1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 3.6 mm
F-number: F1.0
Field of View (FOV): 27.8° × 37.2°
Spatial Resolution (IFOV): 3.3 mrad
Min. Focus Distance: 0.3 m (0.98 ft)
Focus Mode: Focus Free
Image Display
Display: 240 × 320 Resolution, 3.2”LCD Screen
Image Modes: Thermal/Visual/Fusion/PIP
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow
Color Alarm: Above alarm
Visual Camera 1600x1200 (2MP)
Measurement and Analysis
Object Temperature Range: -20°C to 550°C (-4°F to 1022°F)
Accuracy: Max. (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)
Measurement Tools: Center Spot, Hot Spot, Cold Spot
Level and Span Mode: Auto/Manual
Data Storage and Communication
Storage Media: Built-in 16 GB flash memory
Image Storage Capacity: Approx. 90,000 Images
General
Wi-Fi 802.11 b/g/n (2.4 GHz)
USB Interface: USB Type-C
Led light: Yes
Battery Type: Rechargeable Li-ion battery
Battery Charging Time: Approx. 3 hours fully charged
Battery Operating Time: Approx. 6 hours
Protection Level: IP54
Drop Test Height: 2 m (6.56 ft)
Working Temperature Range: -10°C to 50°C (14°F to 122°F)
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 380 g (0.84 lb)
Dimension: 221.7 mm × 73.5 mm × 123.8 mm (8.73'' × 2.89'' × 4.87'')
Tripod Mounting: UNC ¼”-20
