Master control unit: High-performance ARM processor
Monitor: 7-inch true color LCD screen, resolution 1280×800
Storage capacity: 64 GB internal storage (supports Micro-SD expansion)
Operating method: Capacitive touchscreen
Data transfer: WiFi, USB flash drive, USB cable
A/D sampling accuracy: 24-bit
Sampling frequency: 24 kHz, 36 kHz, 48 kHz, 72 kHz selectable
Sampling length: 1024, 2048, 4096 selectable
Sensor type: Acceleration sensors
Sensor sensitivity: ≥100 mV/g
Sensor range: 50 g
Frequency range: 0.5 Hz – 9 kHz
Resolution: 0.0002 g
Impact resistance: 1500 g
Instrument gain: 1, 2, 4, 8 times adjustable
Power supply: Built-in non-removable lithium battery
Working time: Collector >8 h; plate >15 h
Wireless connection: WiFi, Bluetooth
Operating temperature: -10 to +50 °C
Working environment: ≤90% RH
Cloud upload: Supported
Operating mode: Single speed mode
Channel number: 1 channel
Dimensions: 215.6 × 135.8 × 18.9 mm
Weight: 558 g
