Sensor Type: 90° light scattering 880nm
Calibration: Calibrated against Gravimetric reference NIST traceableSAE fine test dust ISO12103-1 A2 Fine Test Dust.
Accuracy: +/- 10% to filter gravimetric SAE fine test dust
Precision: +/- 2 ug/m3 or 0.002 mg/m3
Sensing Range: 0.001-500 mg/m3 or 1-500.000 ug/m3
PM Size Range: 0.1 to 100ųm
Minimum Resolution: 1 ug/m3 (0.001 mg/m3)
Humidity: 95% non-condensing
Temperature: 0-50 C°/32-122 F°
Barometric Pressure: 28-2.5-30.75 Hg 956.6-1041.3 mb
Display: 3.5”, 24-bit True color, Resistive Color Touch, with Auto Dimming, Real-Time Data
Time: Hours, min., sec., 12hour & 24 hour
Display
Date: MM/DD/YYYY, YY/MM/DD, DD/MM/YY
Data Display: Concentrations (mg/m3, ug/m3), Sampling Size Fraction of PM (OSHA TWA, AVE., MAX., MIN.), Start time, stop time, elapsed run time, Log rate, Flow, Real-Time Rolling Graph, Personalized Named Data Sets, Unique Aerosol Profiles, Language Options, Battery Life Pump Faults, Flow Rate, In Field Calibration Test, History of Data Sets
Sampling Flow Rate: 1.5 LPM user adjustable.
Impactors TSP and PM-1.0: PM10, PM5.0, PM4.0, PM2.5
Alarm Output: Audible & Visual
Audible: 90db at 3ft
Ceiling and S.T.E.L Alarms, Pump Fail, and Low Battery
Recording Time: 1 second to 15 days
Sampling Rate: 1 sec., 4 sec., 10 sec., and 60 sec
Data Storage: 43.200 data points
Memory & Time Storage: >5 years
Digital Output: Micro USB 6.00’ (1.83m), A Male to Micro B Male, 28SWG, Shielded
Power Supply: Wall Mount, Multi Bald Included, Voltage Input 100~240 VAC, Voltage Output 12V, Current Output 2A, CE, UL, CB, cUL, PSE, RCM
Battery: Lithium Ion pack, 7.4 Volt 3350 mAh, 24.79 watts
Operating Time: 10 hours Operating & Storing Conditions
Operating Temperature: 0 to 50°C
Storage Temperature: -20 to 70°C
Operational Humidity: 0-95% Non-Condensing
Dimensions: 10”x 3.5” x 1.5”
Weight Instrument: 1.4lbs
Display dimensions: 3.5”
