■ Specifications
Working voltage range: AC 80~7000V
Operation starting voltage (Voltage to ground):
Low voltage: Exposed live part 80 V (in contact with live part)
High voltage: Exposed live part 400 V (in contact with live part)
Insulated wire: (φ5mm OE wire) 3.000 V
Frequency: 50/60Hz
Insulation resistance: 100 MΩ or more between detector and grip
Dielectric strength: 20 kV for 1 min between contact tip and grip
Leakage current: 0.5 mA or less at dielectric strength test
Battery: LR44(1.5V) × 2 pcs
Battery life: 3 hr. in continuously operating state; about 2 years in unused state
Operating temperature range: -10℃~+40℃
Weight: About 55g
■ Option: Storage case (DA04003), Contact tip for replacement (UH05004)
Datasheet
