Pitch: 1.27 mm (0.05 in)
Wire Gauge: 30 AWG
Row Spacing: 1.27 mm (0.05 in)
Unit Weight: 361 mg
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 500 mA
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 12 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
