Pitch: 1.27 mm (0.05 in)
Application: Wire-to-Board
Row Spacing: 1.27 mm (0.05 in)
Unit Weight: 148 mg
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: SMD/SMT
Number of Rows: 2 Row
Voltage Rating: 250 V
Contact Plating: Gold
Contact Material: Brass
Housing Material: Thermoplastic
Termination Style: Solder
Mating Post Length: 3 mm (0.118 in)
Flammability Rating: UL 94 V-0
Number of Positions: 12 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
