Pitch: 3 mm (0.118 in)
Wire Gauge: 22 AWG to 18 AWG
Row Spacing: 3 mm (0.118 in)
Unit Weight: 1.713 g
Contact Type: Pin
Housing Color: Green
Contact Gender: Pin (Male)
Housing Gender: Male
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Housing Material: Nylon
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Number of Positions: 10 Position
Insulation Resistance: 100 MOhms
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 65 C
