HARTING 14020814101000 Fixed Terminal Blocks 8P 30-16 AWG spring 300V 10A 3.5mm THR
Manufacturer: HARTING Model: 14020814101000 - Contact
Pitch: 3.5 mm
Height: 14.85 mm
Length: 28 mm
Unit Weight: 7 g
Current Rating: 10 A
Mounting Angle: Vertical
Mounting Style: PCB Mount
Voltage Rating: 300 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 30 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 30 AWG to 16 AWG
Connection Method: Spring Cage
Termination Style: Through Hole
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
