Measurement Range:
LT glass: 0 to 12 pH
HT glass: 0 to 14 pH
HF glass: 0 to 10 pH
Reference Cell Type: double junction
Type of Electrolyte: polymer
Body Material: PVDF
Glass Type: based on configuration: LT (low temperature), HT (high temperature), or HF (hydrofluoric acid)
Tip / Shape: flat
Environment:
LT glass -5 to 80 ?C (23 to 156 ?F)
HT glass 0 to 100 ?C (32 to 212 ?F)
HF glass F- < 2g/L, temperature 2
Matching Pin: yes
Max. Pressure: 6 bar (87 psi)
Body Length/Overall Length: 140 mm
Temperature Sensor: pt100
Outer Diameter: 22.5 mm
Output Signal: digital RS485
Connector Type: direct wire connection
Probe Mounting: 3/4 in. NPT threaded connection for in-line mounting or submersion mounting with probe holder
