Cooling capacity
KCAL/H 50/60Hz: 18600/22500
W 50/60Hz: 21600/26100
BTU/H 50/60Hz: 74000/89000
Temperature controller
A: Fixed temperature control type (setting range: 10 - 40 °C)
B: Differential temperature control type (tracing ambient/machine body temperature, setting range: -9.9 to +9.9 °C)
Power source: 3Ø 200-230V 50/60Hz
Power Consumption (W): 8300
Pump
W: 860/1510
Max. flow rate (L/min): 80/100
Max. liquid lift (m): 23/34
Min. flow requirement of cooling water (L/min): 70
Piping Diameter (PT)
Liquid inlet: 1-1/4"
Liquid outlet: 1-1/4"
Cooling water inlet: 1-1/4"
Cooling water outlet: 1-1/4"
Water tank capacity: 170L
Dimension WxDxH (mm): 890x890x1255
Weight (KG): 406
Noise level: Below 80 dB(A)
