Cooling capacity
KCAL/H 50/60Hz: 5000/6000
W 50/60Hz: 5820/6980
BTU/H 50/60Hz: 20000/24000
Temperature controller
A: Fixed temperature control type (setting range: 10-40 °C)
B: Differential temperature control type (tracing ambient/machine body temperature, setting range: -9.9 to +9.9 °C)
Use range
Ambient temperature: 10-40°C (Standard)
Liquid temperature: 10-30°C
Power source: 3Ø 200-230V 50/60Hz
Power Consumption (W)
Compressor: 2480
Fan Motor: 350
Pump: 750
Pump flow rate (L/min)
50Hz: 58
60Hz: 75
Max Lift from pump (M)
50Hz: 28
60Hz: 40
Piping diameter
Inlet: PT 1"
Outlet: PT 1"
Dimension WxDxH (mm): 500 x 732 x 1295
Weight (KG): 152
Noise level: Below 80 dB(A)
