Cooling capacity:
KCAL/H 50/60Hz: 5000/6000
W 50/60Hz: 5820/6980
BTU/H 50/60Hz: 20000/24000
Temperature controller:
A: Fixed temperature control type (setting range 10-40 °C)
B: Differential temperature control type (tracing ambient/machine body temperature, setting range -9.9~+9.9°C)
Use range:
Ambient temperature °C: 10-40°C (Standard)
Oil temperature °C: 10-45°C
Power source: 3Ø 200-230V 50/60Hz
Motor (W):
Compressor: 2480
Fan: 350
Piping diameter:
Inlet: PT 1"
Outlet: PT 1"
Dimension WxDxH (mm): 620x1080x1260
Weight (KG): 208
Noise level: Below 80 dB(A)
