Power (W): 15000 W
Current(Ampere): 112.5 Arms / 337.5Apeak
Voltage: 50~425Vrms / 600Vdc
FREQUENCY Range : DC,40~440Hz(CC,CP Mode) , DC~440Hz(LIN,CR,CV Mode)
Constant Current Mode for Sine-Wave
Range: 0~112.5A
Resolution: 1.875mA/16bits
Linear Constant Current Mode
Range: 0~112.5A
Resolution: 1.875mA/16bits
Constant Resistance Mode
Range: 0.533 ohm～10.666K ohm
Resolution: 0.031248mS/16bits
Constant Voltage Mode
Range: 50~425Vrms / 600Vdc
Resolution: 0.1V
Constant Power Mode
Range:15000 W
Resolution: 1W
Dimension( H x W x D ): 814 x 480 x 590 mm
Weight: 140kg
Optional Accessories
PEL-022 GPIB Card
PEL-023 RS-232 Card
PEL-024 LAN Card
PEL-025 USB Card
PEL-025 USB Card
