Power: 0~4KW / 0 ~ 6k max.
Current: 0 ~ 160A/ 0 ~ 240A max.
Voltage:
Min.Operatting Voltage: 15V@100A
Protections
Over Power Protection(OPP): 105%
Over Current Protection(OCP): 104%
Over Voltage Protection(OVP): 105%
Over Temp Protection(OTP): 90°C±5°C
Constant Current
Mode
Range: 0~16A/ 0~160A
Resolution: 0.256mA /2.56mA
Constant
Resistance Mode
Range: 450kΩ ~ 7.5Ω/ 7.5Ω ~ 0.0937Ω
Resolution: 2.2μS / 125μΩ
Constant Voltage
Mode
Range: 0 ~ 1200V
Resolution: 20mV
Constant Power
Mode
Range: 0 ~ 400W / 400 ~ 4kW
Resolution: 6.4mW / 64mW
Dimension (HxWxD):
177mm x 440mm x 745mm
Weight: 29KG
