GW instek PEL-300 DC Electronic Load (60V, 60A, 300W)
ManufacturerGW INSTEK(View more products from this manufacturer)
ModelPEL-300
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
.
Accessories: ; User Manual x 1; Power Cord x 1
RATING | |
| Operating Volatge | DC 3 ~ 60V |
| Operating Current | 6mA ~ 60A |
| Operating Power | 1 ~ 300W |
| MInimum Operation | 3V |
CV MODE | |
| Operating Range | DC 3 ~ 60V |
| Setting Accuracy | ±(0.1% + 40mV) |
| Setting Resolution | 20mV |
CC MODE | |
| Operating Range | 6mA ~ 60A |
| Setting Accuracy | ±(0.5% + 100mA) for 6.02A ~ 60A ±(0.1% + 10mA) for 0.602A ~ 6A ±(0.1% + 1mA) for 6mA ~ 0.6A |
| Setting Resolution | 20mA for 6.02A ~ 60A 2mA for 0.602A ~ 6A 0.2mA for 6mA ~ 0.6A |
CR MODE | |
| Operating Range | 50mΩ ~ 1kΩ |
| Setting Accuracy | ±(5% + 1Ω) for 100.33Ω ~ 1kΩ |
| Setting Resolution | 330mΩ for 100.33Ω ~ 1kΩ 33mΩ for 10.033Ω ~ 100Ω 3.3mΩ for 1.0033Ω ~ 10Ω 0.33mΩ for 50mΩ ~ 1Ω |
DYNAMIC OPERATION CC MODE ONLY | |
| Frequency Range | 1Hz ~1kHz |
| Resolution | 5Hz for 100Hz ~1kHz |
| Duty Range | 10% ~ 90% |
| Resolution | 1% |
VOLTAGE READBACK | |
| Accuracy | ±(0.1% + 60mV) |
| Resolution | 20mV |
CURRENT READBACK | |
| Accuracy | ±(0.5% + 100mA) for 6.02A ~ 60A ±(0.1% + 10mA) for 0.602A ~ 6A ±(0.1% + 1mA) for 6mA ~ 0.6A |
| Resolution | 20mA for 6.02A ~ 60A 2mA for 0.602A ~ 6A 0.2mA for 6mA ~ 0.6A |
MEMORY | |
| 100 sets | |
TIMER | |
| Range | 1 second ~ 999 minutes 59 seconds |
| Resolution | 1 second |
| Function | for load on |
| POWER SOURCE | |
| AC100V/120V/220V/240V±10%, 50/60Hz | |
ACCESSORIES | |
| User manual x 1 Power cord x 1 | |
| DIMENSIONS & WEIGHT | |
| 255(W) x 145(H) x 346(D)mm Approx. 9kg | |
