OUTPUT CHARACTERISTICS
Output Voltage: 0.000 V – 20.000 V
Output Current: 0.0000 A – 5.0000 A
Output Power: 100 W
CONSTANT VOLTAGE (CV) MODE
Line Regulation: ±(0.01 % of setting + 3 mV)
Load Regulation: ≤ 0.02 % + 5 mV (rated current > 3 A)
Transient Response: < 100 µs
Ripple Noise: 0.8 mVrms
Setting Range: 0 V – 21.000 V
Rise/Fall Time: ≤ 100 ms
Maximum Remote Sensing Compensation Voltage (Single Line): 0.5 V
Temperature Coefficient (Typical): 300 ppm/°C
CONSTANT CURRENT (CC) MODE
Line Regulation: ≤ 0.1 % + 3 mA
Load Regulation: ≤ 0.1 % + 3 mA
Setting Range: 0 A – 5.2500 A
Ripple Noise (Arms): ≤ 2 mArms
Temperature Coefficient (Typical): 300 ppm/°C
DC LOAD MODE
Display Voltage: 3.000 V – 20.000 V
Current: 0 A – 5.0000 A
Power: 100 W
CV Mode Setting Range: 3.000 V – 20.000 V
Setting/Readback Accuracy: ≤ 0.1 % + 30 mV
Resolution: 1 mV
CC Mode Setting Range: 0 A – 5.0000 A
Setting/Readback Accuracy: ≤ ±0.3 % + 10 mA
Resolution: 0.1 mA
GENERAL SPECIFICATIONS
Display: 2.4-inch TFT LCD
Interface
LAN:
MAC Address, Gateway IP Address, Instrument IP
Address, Subnet Mask
USB: Type A: Host, Type B: Slave, Speed: 1.1/2.0, USB-CDC/TMC
GPIB (Factory Optional): SCPI-1993, IEEE 488.2 compliant interface
Power Source: AC (100 V, 120 V, 220 V, 240 V) ± 10 %, 50 or 60 Hz
Power Consumption: 300 VA
Max. Inrush Current: 30 A max or less
Dimensions & Weight: 107 mm x 124 mm x 313 mm (W x H x D) (not including protrusions), Approx. 5.5 kg
