Channels: 2
Waveforms: Sine, Square, Triangle, Ramp, Pulse, Noise, Harmonic wave, Arbitrary wave
Arbitrary Functions
- ARB Function: Built-in
- Sample Rate(*1): 500MSa/s
- Repetition Rate (Arbitrary wave): 30MHz
- Waveform Length: 2-10M points
- Amplitude Resolution: 14 bits
Frequency Characteristics:
- Sine: 60MHz
- Square: 30MHz
- Pulse: 25MHz
- Triangle, Ramp: 3MHz
- Noise (-3dB): 60MHz BW
- Harmonic Wave: 30MHz
- Resolution: 1μHz or 10 significant figures
Advanced Waveform Characteristics
- Modulation Function: AM, DSB-AM, FM, PM, PWM, ASK, PSK, BPSK, QPSK, FSK, 3FSK, 4FSK, OSK, SUM
- Sweep Function: Support
- Burst Function: Support
- Counter Function: Support
General Specifications
- Display: Type: 8-inch color LCD display
Resolution: 800 Horizontal x 480 Vertical pixels
Color: 65,535 colors, 16 bits, TFT
Touch Screen Capacitive: Multi-touch
- Communication Interface: USB Host, USB Device, LAN
- Power: Source: 100-240V (±10%), 50/60Hz
Power Consumption: Less than 50VA
Fuse: 250V, F2AL
Dimensions & Weight: 340 (W) x 177 (H) x 90 (D) mm; Approx. 2.5kg
Included accessories: GTL-101 x2, USB communication cable x1, Power cord x1, Quick Start Guide x1, CD (user manual + communication software) x1
