Test Mode: Series connect, two ports pass through mode.
Insertion loss: <1.5 dB.
PON Data Parsing: OLT information: OLT PON ID, ODN class, Tx power; ONU information: ONU ID, ONU SN.
Power Measurement: Downlink 1490nm and 1577nm; Uplink 1270nm and 1310nm.
Optical Interface: SC/APC ×2.
Charging Port: USB Type-C, 20W quick charger.
Power Supply: 8000mAh lithium battery.
Data Storage: 16G TF Card.
Working Temp: -10°C to 50°C.
Humidity: 5% ~ 95% (no condensation).
Dimension: 193 × 94 × 47 mm.
Weight: 609g.
Display: 3.5 inch color LCD.
Wireless: Bluetooth connection with Android phone app.
