Sensor Type: InGaAs
Working Wavelength: 800~1700nm
Calibrated Wavelength:
Standard: 850/1300/1310/1490/1550/1625nm
Optional: 980nm/1270nm/1577nm/1650nm,etc
Test Range: −70~+10dBm
Accuracy: ±0.2dB
Resolution: 0.01
Frequency Detection: 270Hz/330Hz/1kHz/2kHz
Recognizable Wavelength: 850/1300/1310/1490/1550/1625nm (with FHS2 series laser source)
Frequency Identification Range: −40dBm~+10dBm@1550nm
Wavelength Identification Range: −40dBm~+10dBm@1550nm
Unit display: dBm/dB/mw
VFL(Optional):
Working wavelength: 650±10nm
Output power: 10mW
Working mode: CW/2Hz
Bluetooth(Optional): Can be connected with Android mobile phone software through Bluetooth
Memory Capacity: 999 groups (can be transferred to PC software and generate report)
USB Port: TYPE-C charging/data port
Power Supply: 2 Ni-MH AA battery | Input: AC100~240V, 50/60Hz Output: DC5V/1A
Working Temp: −10℃~+50℃
Storage Temp: −20℃~+70℃
Dimension/Weight: 160L×76W×45H(mm) / 265g
Accessories: 2*Ni-MH AA battery, FC adapter, SC adapter, Power adapter, USB cable, Test report, Quick guide, Carrying bag
