Gossen Metrawatt SINEAX DM5000 Multifunctional Power Meters (PMD) (0…3000A)

Input channels voltage / current: 4 / 4

Measurement interval [ #cycles ]: 10/12 (50/60Hz); 1/2

Inputs

Nominal current: 1 … 5 A (max. 7.5A)

Current measurement via Rogowski coils: Yes

Measurement range: 0…3000A (max. 3800A)

Nominal voltage: 57.7 … 400VLN, 100 … 693VLL

Nominal frequency: 42 … 50 … 58Hz, 50.5 … 60 … 69.5Hz

Weight: 600 g

Protection: IP40 (front), IP30 (housing), IP20 (terminals)

Communication

Ethernet: Modbus/TCP, web server, NTP (standard)

IEC61850: Option

PROFINET IO: Option

RS485: Modbus/RTU (standard)

Standard I/Os: 1 dig. IN ; 2 dig. OUT

Extension modules (optional): max. 2 modules

Power supply

Nominal voltage: 100-230V AC/DC or 24-48V DC

UPS (optional): 5 times 3 minutes

Design

Colour display: TFT 3.5“ (320x240px)
