Display: LCD Graphical /256 x 64 pixels /Backlight
Construction: 8.6 x 24.9 x 27.2 cm/ABS Plastic
Weight: < 5 Lbs (2.3 kg)
Face Plate: Lexan/Back printed
Operating Range :15 to 40 °C
Storage Range: -20 to 65 °C
Power Supply
Battery: 9 V DC [2 required.]/[NE 1604] Alkaline
Power:
BE 2006 PE[220 V AC] US
BE 2006 PE[220 V AC] EU
[10 V, 300 mA]
Method: Biphasic
Load resistance: 50 Ohm +/- 1% non-inductive(<1 µH)
Display resolution: 0.1 Joule
Measurement time window: 100 ms
Absolute max peak Voltage: 6000 Volts
Pulse width: 100 ms
Voltage: Low Range < 1000 Volts; High Range < 5000 Volts
Max current: Low Range : 24 Amps; High Range : 120 Amps
Max energy: Low Range: 50 Joules; High Range : 1000 Joules
