Voltage [V]: 25, 100, 500, 1500
Current [A]: 2, 5, 10, 20
Temperature: -40 ... +120 °C with Pt1000
Irradiation: 0 ... 1300 W/m² (standard sensor)
Sampling rate: Max. 100 kHz
Resolution: 0.01 V ... 0.25 V, 0.005 A ... 0.001 A (depending on the selected measuring range)
Measuring accuracy: Better than 1% (as of 10 W)
Battery: Rechargeable lithium-ion battery, 11.25 V, 8850 mAh, 99.6 Wh (continuous operation: approx. 8 h)
Power consumption: approx. 40 W
External power pack: In: 90 to 263 V AC, 47 to 63 Hz, 60 W
Display: Color LCD with LED backlight
Resolution: 480 x 272 pixels
Protection: IP 20
Dimensions W x H x D: 406 x 330 x 175 mm
Weight: approx. 7.6 kg (without accessories)
