Gossen Metrawatt KE801 LWL Kit Multifunctional Line Tracers (15 km; 25 cm)

Housing: Heavy duty housing made from ABS, elastomeric silicon rubber push buttons

Test Leads: Two 25 cm banana plug test leads made of flexible PVC with clip-on crocodile clips, one test lead with RJ-11 modular plug, one test lead with RJ-45 plug

Further Connectors: Fibre optic laser light source (VFL) 2.5 mm universal ferrule; adapter to 1.25 mm, SMA, and POF available optionally

Search Frequencies:

6 frequencies selectable, accuracy < ±1% (Quartz)

SOLID: 1000, 2600, 577.5 Hz

ALT: 1000/800, 2600/1900, 577.5 Hz intermittent

External Voltage Protection: Up to 120 V AC in any mode

Specifications:

-Continuity test with LED

-Resistance test through frequency change

-Network port test with port finder function

-Low battery indication by flashing LED

-Auto shut-off after 45 minutes

-Auto shut-off override incl. indication through flashing LED

-Device on indication through LED

-Indication of ALTERNATING frequency by flashing LED

-Indication of SOLID frequency by steady LED

-Test leads protected by rubber-strain relief

-Separate battery compartment

Reach: Trace cable length up to 15 km / 9.3 mi (no load)

Transmitting Power:

High power output with 9 V battery

9.0 V PP no load

10 dBm at 600 Ohm

9 dBm at 100 Ohm

7.5 dBm at 50 Ohm

Tone over shorted pair up to 250 m / 0.15 mi

Power Supply: 9 V battery; approx. 20 hours battery life respectively approx. 10 hrs with laser CW (depends on type and state of battery model)

Dimensions/Weight: 68 × 96 × 25 mm / 150 g without battery

PROBE410

Specifications:

Filtered signal LED

Torch light function

Solid carbon fiber tip

3.5 mm earphone jack

Separate battery compartment

Reach: Trace distance to cable/wire up to 60 cm / 23.6"

Power Supply: 9 V battery; approx. 100 hours battery life (depends on type and state of battery model)

Dimensions/Weight: 220 × 40/34 × 25 mm / 80 g without battery
