Gossen Metrawatt K21 Multifunctional Power Meters (PMD) ((L-N): 10…300 V AC; (L-L): 10…500 V A)

Input voltage (L-N): 10…300 V AC, 50-60 Hz

Input voltage (L-L): 10…500 V AC, 50-60 Hz

Input current: 0.05 … 5.5 A

Aux. Power supply: 190-260 V AC, 50-60 Hz

Aux. Power supply power consumption: < 4 VA

Measuring input power consumption: < 1 VA

Class: 1 ±1 digit

Voltage Transformer Ratio: 1 … 2000

Current Transformer Ratio: 1 … 2000

Operating temperature: -5 °C … +50 °C

Display: Red LED

Electric Protection: Double insulation – Class II

Box Protection: IP40, frontal panel

Box Material: Non flamable

Installation: Panel mounted

Installation Category: Class III

Wire Thickness (terminal block): 2.5 mm2

Dimensions: 96 x 96 x 80 mm

Weight: 0.45 kg

Datasheet
