Capacity, m3/hour, minimum/gals. per hour:
• drying, regeneration and filtration mode: 1.7/450
• heating mode: 1.7/450
Max oil outlet temperature, ⁰С/⁰F:
• drying and filtration mode: --
• heating mode: 60/140
Sorbent max load, kg: -
Sorbent regeneration temperature, ⁰С/⁰F:
Zeolite NaA: -
Silica gel: -
Sorbent regeneration without unloading: No
Processed oil parameters:
• industrial purity class (ISO 4406): 9 (-/14/12)
• solid particle content, max, g/t: 2.5
• acid number, mg KOH/g of oil, max: -
• nominal filtration fineness, micron: 5…25
• mass weight content, g/ton per cycle, max: -
• dielectric loss tangent at 90 ⁰С/194 ⁰F, max: -
• dielectric strength, kW, min: -
Mean heater surface power, W/cm2, max: -
Heater power, kW, max: -
Max power consumption, kW: 33
Three phase AC power voltage, 50/60Hz, V: 380/220
Dimensions, mm/ft, max, length/width/height: 1270/700/1400 (4’16”/2’29”/4’59’)
Weight, kg/lbs, max: 500/1,105
