Spectral responsivity:
CH1: UV-A Peak 380 nm: (315 - 400) nm
CH2: UV-B Peak 311 nm: (280 - 315) nm
Typical responsivity:
CH1: 7 nA/(W/m²)
CH2: 9 nA/(W/m²)
Max. signal current:
CH1: 100 µA
CH2: 50 µA
Input optics: 8 mm Ø Diffuser
Measurement ranges:
XD-9503-CH1
min (0.1 pA NEI): 1.43E-05 W/m²
max (100 µA): 1.43E+04 W/m²
XD-9503-CH2
min (0.1 pA NEI): 1.11E-05 W/m²
max (50 µA): 5.56E+03 W/m²
Temperature range: 5 - 40°C
Cable Length: 2m
Plug Types: -4
