Spectral responsivity: radiometric (400 - 500) nm
Typical responsivity: 35 nA/(W/m²)
Max. signal current: 1 mA
Input optics: 11 mm Ø diffusor window
Input optics: Cosine F.O.V.
Housing: 37 mm Ø, 32 mm height
Mounting: side M6 thread hole
Connector: coaxial cable 2 m Long, with ITT (-4) connector
Temperature range: 5 - 40°C
min. signal current: depends on optometer
Rise time: 2.5 µs
Measurement ranges:
min (0.1 pA NEI): 2.86E-06 W/m²
max (200 µA): 5.71E+03 W/m²
max (1 mA): 2.86E+04 W/m²
