Sphere diameter: 16 mm
Size input optic: 3 mm
Spectral range: 400 - 1100nm
Coating: Bariumsulfate
Rise time: 100 ns
Max. signal current: 1 mA
Typical responsivity: 2.10E-04 A/W @ 633 nm
Measurement ranges:
min (0.1 pA): 4.76E-10 W
max (200 µA): 9.52E-01 W
max (1 mA): 4.76 W
Temperature range:
Application: (10 to 30)°C
Storage: (-10 to 50)°C
Humidity: The device must not be exposed to high humidity. Range 20% ~ 70% RH not condensing.
